Stainless Steel Gear Pump

Name: Stainless Steel Gear Pump
Brand: MACH POWERPOINT PUMPS INDIA PVT. LTD.
Price: 27600.0 INR
Availability: InStock

Price 27600.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Stainless Steel Gear Pump Specification

Flow Rate
10-500 LPH or as specified

Caliber
1/2 inch to 2 inch

Max Suction
5 meters

Features
Corrosion Resistant, Leak Proof, High Efficiency

Discharge Pressure
Up to 10 Bar

Voltage
220/415 Volt (v)

Inlet/Outlet
Threaded / Flanged (options available)

Mounting Type
Horizontal, With Base Plate

Noise Level
Low (65 dB)

Frequency
50 Hz / 60 Hz

Head Size
10-50 meters

Fuel Tank Capacity
N/A (Electric Driven)

Control System
Manual / Automatic (optional)

Working Temperature
-10C to 120C

Speed
1400-2800 RPM

Theory
Rotary Gear Pump

Material
Stainless Steel (SS-304/316)

Structure
Coupled with electric motor and base frame

Power
0.5 HP to 5 HP

Standard
CE/ISO 9001 Certified

Fuel Type
Electric

Pressure
Up to 10 Bar

Usage
Chemical, Pharmaceutical, Food, Oil Transfer

Application
Industrial Transfer, Dosing, Circulation

Suction Type
Positive Displacement

Seals Type
Mechanical Seal / Gland Packing

Priming
Self-priming

Pump Type
Stainless Steel Gear Pump

Capacity
Up to 500 LPH

Viscosity Range
Up to 100,000 cSt

Maintenance
Easy Maintenance Design

Ambient Temperature Range
Up to 50C

Fluid Compatibility
Acids, Bases, Solvents, Oils, Food Products

Surface Finish
Mirror Polish (optional)

Bearings
Heavy Duty Ball Bearings

Rotation Direction
Clockwise/Counterclockwise (customizable)

Drive Type
Direct Coupled

Impeller Type
External Gear

Protection Class
IP55 / IP65 (subject to motor type)

Installation
Skid Mounted or Standalone

Lubrication
Self-lubricated or external

Shaft Material
Stainless Steel

Stainless Steel Gear Pump About

Buy the Stainless Steel Gear Pump for ace industrial applications requiring rare reliability and dazzling performance. This uncommon pump is crafted with stainless steel (SS-304/316) for corrosion resistance and comes with a direct coupled drive type, supporting both clockwise and counterclockwise rotation. Get customizable viscosity up to 100,000 cSt, suitable for transferring chemicals, pharmaceuticals, food, and oils. Enjoy self-priming, leak-proof operation, and easy maintenance. Available in multiple protection classes and configurations, this high-efficiency, positive displacement pump ensures dazzling durability and performance, making it ideal for exporters, importers, and manufacturers alike.

Advantages & Application of Stainless Steel Gear Pump

The Stainless Steel Gear Pump stands out for its high corrosion resistance and robust build, thanks to the use of superior SS-304/316 stainless steel. Its dazzling efficiency and leak-proof design make it ideal for transferring aggressive chemicals, oils, food products, and pharmaceuticals. With a positive displacement suction and self-lubrication, it guarantees smooth operation in dosing, circulation, and industrial transfer tasks, delivering consistent performance in challenging environments up to 120C.

Delivery Time, Exchange, and Sample Policy Details

Shipped goods are typically delivered quickly, depending on order size and specifications, with standard lead times provided upon valuation. Sample policies allow you to examine the pump's build and performance before purchase-samples are available upon request and may be provided against a refundable exchange or nominal fee. The company ensures a smooth ordering process with transparency in shipping timelines and flexibility in handling quotations for bulk requirements or special configurations.

FAQ's of Stainless Steel Gear Pump:

Q: How can I customize the rotation direction of the gear pump?

A: The rotation direction of our Stainless Steel Gear Pump can be configured for clockwise or counterclockwise operation during ordering, enabling adaptation to your specific pipeline or application needs.

Q: What is the process to request a sample for evaluation?

A: To request a sample, simply contact our sales team. Samples are available for valuation and review under our sample policy, generally provided on payment or exchange basis, ensuring you can examine the quality before placing a larger order.

Q: Where can these pumps be used most effectively?

A: These pumps are best applied in industries such as chemical processing, pharmaceuticals, food production, and oil transfer due to their compatibility with a wide range of fluids and robust corrosion-resistant construction.

Q: What advantages does the mirror polish surface finish provide?

A: The optional mirror polish finish offers superior corrosion resistance, makes cleaning easier, and ensures optimal sanitation standards, particularly important for food and pharmaceutical applications.

Q: How is maintenance of the Stainless Steel Gear Pump made easy?

A: The pump features a user-friendly design allowing quick disassembly and routine servicing, with heavy-duty ball bearings and leak-proof seals that minimize maintenance requirements and extended operational life.
